This aluminium rose fixing kit is ideal for suspended luminaires with a top opening of between 73mm (to allow the three screws to pass through) and 110mm (maximum diameter covered by the top ring).
Thanks to this kit, you can easily install and secure your suspended luminaire in complete safety. This aluminium rosette is ideal for creating a trendy modern or older-style pendant.
The aluminium material of this fixing kit means that it can be painted to suit your needs, allowing you to choose the colour that best matches your suspended luminaire.
'
Features:
For 73 to 110 mm diameter holes
Material: aluminium
Thread: three times M3
Dimensions: external diameter 110mm, boss thickness 10.7mm
Centre hole: 10.5 mm
Weight: 96gr
Kit sold individually without screws
Maximum load: 8 kg
This kit includes a two-part hemispherical aluminium rosette and a slotted flange with 3 M3 holes tapped at 120 degrees.
Please note that the screws are not included in this aluminium rose fixing kit. You will therefore need to choose the appropriate screws according to the thickness of your luminaire.
Screws of different lengths are available at the bottom of the product data sheet so that you can choose the ones best suited to your installation.
The maximum recommendedload for this product is strictly dependent on the system we offer, excluding any consideration for additional fixing accessories you may use.
This load limit is directly related to the strength of the three screws used to secure the whole kit.
It is important to note that the load capacity of the fixing kit is in no way influenced by the choice of cable suspension system or any other fixing mechanism.
